Knowledge of PVC sheet

Knowledge of PVC sheet

PVC board is a board made of PVC as a raw material with a honeycomb mesh structure.
PVC boards account for the largest proportion in the building materials industry, at 60%, followed by the packaging industry, as well as several other small-scale applications. According to the degree of hardness, it can be divided into soft PVC and hard PVC. According to the production process, it can be divided into PVC crust foam board and PVC free foam board. According to transparent and opaque, it can be divided into PVC transparent board and pvc board.
Chinese name PVC board Foreign name PolyVinyl Chloride category PVC skinned foam board and PVC free foam board PVC laminate PVC and stabilizer and other auxiliary materials are calendered
table of Contents
1 Meaning
▪ PVC
▪ Product description:
▪ Product features:
▪ UPVC
2 Performance
3 categories
4 Market prospects
5 Classification examples
▪ Anti-static
▪ Transparent board
▪ Soft board
▪ Plastic board

PVC
The PVC board is a board made of PVC as a raw material and has a honeycomb mesh structure in cross section, and is a vacuum plastic film. It is used for surface packaging of various types of panels, so it is also called decorative film and adhesive film. It is used in many industries such as building materials, packaging, medicine and so on. Among them, the building materials industry accounted for the largest proportion of 60%, followed by the packaging industry, as well as several other industries with small scope of application. According to the degree of softness and rigidity, it can be divided into soft PVC and hard PVC, and according to the production process, it can be divided into PVC crust foam board and PVC free foam board.
Information title: Supply PVC board, extruded board, laminated board, non-fired brick pallet.
Keywords: PVC board, plastic board, PVC pallet, non-fired brick pallet.
Polyvinyl chloride (PVC) plastic is a polymer formed by free radical polymerization of vinyl chloride monomer. The English name is polyviny chloride, or PVC for short. PVC can be divided into soft PVC and hard PVC. Among them, hard PVC accounts for about 2/3 of the market, and soft PVC accounts for 1/3.
Soft PVC is generally used for the surface layer of floors, ceilings and leather, but because soft PVC contains softeners, it is easy to become brittle and not easy to preserve, so its scope of use is limited. Hard PVC does not contain softeners, has good flexibility, is easy to form, is not brittle, non-toxic and non-polluting, and has a long storage time, so it has great development and application value.
PVC foam board has the characteristics of anti-corrosion, moisture-proof, mildew-proof, non-absorbent, drillable, sawable, planable, easy to be thermoformed, and hot-bending, etc. Cabinet core layer, indoor and outdoor decoration, building materials, chemical industry and other fields with boards, advertising signs, printing, silk screen, inkjet, computer lettering, electronic instrument product packaging and other industries.
PVC rigid plastic board has excellent corrosion resistance, insulation, and has a certain mechanical strength; after secondary processing can be made into sulfuric acid (hydrochloric acid) tank (barrel box); empty needle rack for medicine, chemical rack; public Toilet water tank; various shaped products and containers such as templates, decorative plates, exhaust pipes, equipment linings, etc. for processed products. It is an ideal material for chemical industry, building materials, decoration and other industries.
Retired to second place in the late 1960s. Due to the abundant raw materials for PVC resin synthesis, the demand for low prices has increased rapidly, and its position has gradually strengthened. The average polymerization degree of general-purpose PVC is 500 ~ 150, and the average polymerization degree of high-degree and high-degree PVC is more than 1700. Our commonly used PVC resins are all universal.
product manual:
Hardness PVC board: The quality of this product is GB / T4454-1996, which has good chemical stability, corrosion resistance, high hardness, high strength, high strength, UV protection (aging resistance), fire resistance (self-extinguishing) , Reliable insulation performance, smooth and smooth surface, no water absorption, no deformation, easy processing and other characteristics. This product is an excellent thermoforming material and can replace some stainless steel and other corrosion-resistant synthetic materials. It is widely used in chemical, petroleum, electroplating, water purification treatment equipment, environmental protection equipment, mining, medicine, electronics, communications and decoration and other industries .
Product thickness: 0.8-30mm Product width: 1300mm 1500 mm Length: Can be produced according to customer needs.
PVC soft board
PVC soft board
Laminated sheet: 2-60mm Product width: 1000mm × 2000 mm.
PVC transparent board: This product is a high-strength, high-transparent plastic sheet produced by our company by introducing advanced foreign technology and using advanced imported raw and auxiliary materials. The product colors are white, gem blue, brown, brown and other varieties. The product has high strength, high transparency, good weather resistance, non-toxic, hygienic and physical properties superior to organic glass. Widely used in equipment guards, interiors, drinking water tanks, liquid level display, etc.
Product thickness: 2-20mm Maximum product width: 1300mm.
Product length: 100-10000mm Recommended specifications: 1300 × 2000mm.
PVC soft board (coiled material): the surface is glossy and soft. There are a variety of colors such as brown, green, white, gray and so on. The product is superior in material, fine in production and widely used. Performance characteristics Soft and cold resistance, wear resistance, acid resistance, alkali resistance, corrosion resistance, tear resistance, excellent weldability, physical properties are superior to other coils such as rubber. Used in chemical industry, electroplating, lining of electrolyzer, insulating cushion, train, automobile interior and auxiliary materials.
Product thickness: 1-10mm Product maximum width 1300mm
Product length: unlimited, recommended specifications: width 1300 mm, weight 50kg / roll
PVC welding rod: This product is specially used for the welding of PVC transparent board. The specification is 1.5-3mm, length is 1000mm, and there are single and double root varieties.
PVC Andy board is also known as Chevron board and PVC foam board, its chemical composition is polyvinyl chloride, English name pvc foam board.
Features:
1. Waterproof, flame retardant, acid and alkali resistant, mothproof, light weight, thermal insulation, sound insulation and shock absorption.
2. The same processing as wood, and the processing performance is far superior to wood.
3. It is an ideal substitute for wood, aluminum and composite plates.
UPVC
Board thickness: 2.0mm-3.0mm
Weight: 2.5--4.5 kg / m2
PVC board
PVC board
Applicable temperature: -50 ℃ -70 ℃
Tensile strength: 29.4mpa
Bending strength: 45.6mpa
Low temperature (-5 ℃ drop hammer impact): 10 times zero crushing
Color: According to customer requirements
Life: not less than 50 years
product manual:
1. Excellent weather resistance-service life is not less than fifty years
It adopts a unique super weather-resistant and anti-aging formula design, which has been verified by practice: it has shown good application in various climatic conditions such as Russia, mainland China, southeast coast, Southeast Asia and so on.
2. Outstanding waterproof performance-no need to set waterproof layer
It is free of water-proof layer when used in roof constructions with slopes between 15 degrees and 90 degrees. The material characteristics, structure, patented accessories and scientific and reasonable installation methods of the color tiles make the roof a whole waterproof system.
3. Wind resistance and earthquake resistance-90 degrees building facade decoration is safe and reliable
No matter it is used in villas or high-rises, inland or coastal areas, it can resist hurricanes and earthquakes, and the roof system is safe and reliable.
4. Rich colors, novel personality, lasting and stable
pvc hard board
pvc hard board
The selection of twenty-five colors is your architectural personality. The color tile surface is smooth and has strong acid and alkali resistance, so it will not be mildewed and corroded in any environment, and it will rain like new.
Fifth, good fire performance meets the national fire protection requirements for roofing materials, meets the flame retardant standard, and effectively delays the spread of fire.
Sixth, heat insulation, thermal insulation-roof tiles with the highest thermal insulation performance
The thermal conductivity of the 2.2mm thick Fanmei fluorine plastic color tile is only 0.06kcal / m.h. ℃, which is 6 times the thermal insulation performance of 15mm cement tile.
7. The sound insulation performance of the porous material of the core layer causes the sound energy to decline due to friction in the porous wall, thereby producing a sound absorbing effect and protecting the rooftop residents from noise.
8. Excellent toughness and strength
The unique three-layer composite structure, two-way drawing process and selected raw materials make it
PVC plastic board
PVC plastic board
It has better toughness and strength than similar products.
Nine, simple construction-the fastest pavement speed and the lowest construction cost
Fanmei fluorine plastic color tiles can easily handle special shapes such as facades and arc windows. Large area, light weight, and light handling; can be directly nailed, sawed, drilled, and planed.
Ten, economical savings-can save about 20 yuan per square meter
Fanmei fluorine plastic color tile slope roofing system is the roofing tile category with the lightest weight and the lowest cost among the middle and high grade slope roofing.
Performance editing
General performance PVC resin is a white or light yellow powder with a relative density of 1.35-1.45. The hardness of the product can be added by
PVC transparent board
PVC transparent board
Adjust the number of plasticizers. Pure PVC has low water absorption and permeability.
Mechanical properties PVC has high hardness and mechanical properties. It increases with the increase of molecular weight, but decreases with the increase of temperature. Hard PVC has good mechanical properties, and its elastic modulus can reach 1500-3000MPa. The elasticity of soft PVC is 1.5-15 MPa. But the elongation at break is as high as 200% -450%. The friction of PVC is general, the static friction factor is 0.4-0.5, and the dynamic friction factor is 0.23.
Thermal properties The thermal stability of PVC is very poor. It begins to decompose at 140 ° C and the melting temperature is 160 ° C. The coefficient of linear expansion of PVC is small, it is flame retardant, and the oxidation index is as high as 45 or more.
Electrical properties PVC is a polymer with better electrical properties, but due to its greater polarity, its electrical insulation is not as good as PP and PE. Dielectric constant, dielectric loss tangent and volume resistivity are large, corona resistance is not good, generally suitable for low-voltage and low-frequency insulating materials.
Environmental performance PVC is resistant to most inorganic acids, alkalis, salts, and most organic solvents. Suitable for pharmaceutical and chemical anti-corrosion materials.
Category editing
Anti-static pvc board
Anti-static pvc board (anti-static polyvinyl chloride board)
The flame retardant grade is ul-94: v-0.
colour:
Transparent, smoke, milky white, gray, etc.
application:
Equipment cover, dust-free box, test fixture, etc. [2]
PVC hard board
The rigid PVC extruded sheet is produced from the world's advanced flat CM80 conical twin-screw extrusion production line imported from the Cincinnati Milakron Company in Austria. The product quality is first-class, the color is generally gray and white, and PVC color hard board can also be produced according to customer needs. Its color is bright and beautiful.
Product thickness upper limit: below 25mm.
Product width: 900mm, 1300mm, 1500mm.
Performance characteristics: [PAGE]
The quality of this product is implemented in GB / T13520-1992. It has excellent chemical stability, corrosion resistance, high hardness, no water absorption and deformation, and easy processing.
use:
The product is an excellent thermoforming material, which can replace part of stainless steel and other corrosion-resistant synthetic materials.
PVC transparent board
Product thickness upper limit: below 20mm
Maximum product width: 1300mm
Specification: 1300
Market Outlook Editor
PVC is everywhere in people's daily lives. PVC can express not only the colors of nature, but also the colors that people imagine. In Germany, 40% of furniture is made of PVC, such as desks, bookshelves, sofas, kitchen cabinets, etc. It is very popular in today's world
PVC foam board
PVC foam board
A synthetic material that is loved, popular, and widely used. Its global usage ranks second among various synthetic materials. According to statistics, in 1995 alone, PVC production in Europe was about 5 million tons, while its consumption was 5.3 million tons. In Germany, the production and consumption of PVC averages 1.4 million tons. PVC is being produced and applied all over the world at a growth rate of 4%. The growth rate in Southeast Asia is particularly remarkable.

anti-static
Anti-static pvc board (anti-static polyvinyl chloride board)
The flame retardant grade is ul-94: v-0.
colour:
Transparent, smoke, milky white, gray, etc.
application:
Equipment cover, dust-free box, test fixture, etc.
cant see thing
The product adopts a high-strength, high-transparent plastic sheet produced by high-grade imported raw and auxiliary materials. The product colors are white, gem blue, brown, brown and other varieties.
Product thickness upper limit: below 20mm
Maximum product width: 1300mm
Specification: 1300 × 2000mm
Performance characteristics:
This product is superior to organic glass in high strength, high transparency, good weather resistance, non-toxicity, hygiene and physical properties.
Uses: This product is widely used in equipment guards, interiors, drinking water tanks, liquid level display, etc.
Soft board
The surface of PVC soft board (coiled material) is shiny and soft. Available in various colors such as brown, green, white, gray, etc. The product is made of materials, made fine, and widely used.
Maximum width: 1300mm
specification:
1300mm wide, 50kg / bundle
Performance characteristics:
It is soft, cold-resistant, wear-resistant, acid-resistant, alkali-resistant, corrosion-resistant and tear-resistant. It has excellent weldability and better physical properties than other coiled materials such as rubber.
use:
Used in chemical industry, electroplating, lining of electrolytic cell, insulating cushion, train, automobile interior and auxiliary materials, etc.
Plastic plates
The product is a superior thermoformed plastic that can replace some stainless steel and other corrosion-resistant synthetic materials. It is widely used in chemical industry, petroleum, electroplating, water purification equipment, environmental protection equipment, mining, medicine, electronics, communications and decoration industries.
