PE CARBON SPIRAL PIPE MACHINE PARAMETERS

The equipment occupies a small space and has no strict requirements on the user's workshop. The company also designed the container line equipment to reduce the transportation cost of customers' plastic pipes. Customers only need to provide power and water sources to directly produce prestressed plastic spiral corrugated pipes, which facilitates transportation between customer sites and reduces transportation costs. This is a major feature of our company and is favored by our customers! The complete set of equipment consists of SJ series single screw extruder → extrusion die → spiral forming die → vacuum spray water tank → tractor → sawing machine → reverse platform. One: Equipment advantages: 1. Fast production speed, twice that of manufacturers in the same industry. 2. Advanced formula technology, low cost and high quality. 3. The whole machine runs steadily, has high reliability, and is easy to maintain, so as to avoid delaying the construction period. 4. The round pipe and flat pipe are operated by one machine, the equipment investment cost is low, and the bellows produced are more resistant to impact than the slub bellows. Second, the equipment technical parameters: host model: SJ65 / 30, SJ70 / 33, SJ75 / 30, SJ80 / 30, SJ90 / 30, mold specifications: φ40-φ140 (forming machine * large production diameter: φ200, replace the mold to produce Carbon spiral tube) Cooling method: water-cooled traction speed: 0.5-3m / min vacuum pump power: 4kw water pump power: 1.5kw total power: 45-58kw unit weight: 5000-6000kg Dimensions: 20000 × 1200 × 1850mm

Third, compared with plastic slub bellows equipment:

Prestressed plastic spiral tube

Prestressed plastic bellows

Ring stiffness

S = 950KN / m2

S = 800KN / m2

* Small bending radius

0.9-1.5 meters (about 6-8 times the inner diameter or the long and short axis)

0.9-1.5 meters (about 10-15 times the inner diameter or the long and short axis)

Exterior

The inner and outer walls are smooth and there is no clamping line

There is mold clamping line, easy to crack when doing ring stiffness experiment

Mould

Low mold cost, short mold change time, high efficiency, and easy adjustment

High mold price, long mold change time, complicated adjustment, and high level of worker operation

Join

You can use the freshman size pipe as a joint, screw connection, convenient, no waste pipe, no need to add any equipment

Injection parts must be used as joints, equipment or outsourcing must be purchased

Flat tube

Can produce spiral flat tube

Must add mold


If you want to know more about it please do not hesitate to contact me. WhatsApp:+86-15966835076
Four, pipe specifications:



model

Inner diameter d, mm

Outer diameter D, mm

Wall thickness S, mm

Out of roundness

Nominal value

deviation

Nominal value

deviation

Nominal value

deviation

SBG-50Y

50

± 1.0

63

± 1.0

2.5

0.5

6%

SBG-60Y

60

73

2.5

SBG-75Y

75

88

2.5

SBG-90Y

90

103

2.5

SBG-100Y

100

± 2.0

116

± 2.0

3.0

SBG-115Y

115

131

3.0

SBG-130Y

130

146

3.0
