all kinds of wpc products formula for reference
Reference formula for door cover line, skirting line, sliding door series
Name
Added amount (kg)
PVC
100
Light calcium
100-130
Wood flour
10-20
Stabilizer YY602
4-5
Foaming modifier YY50
6-8
CCR10
1
CCR20A
0.8-1
YY45
Around 1-1.3
YY46
Around 0.9-1.2
Soybean oil
Add as needed
Wood plastic door, cabinet board, *** hollow board reference formula
Name
Add amount
PVC
100
Wood flour
10-15
Light calcium
80
Stabilizer YY602
6
YY50
2
YY52
7
CCR10
0.8
CCR20A
0.8
YY45
Around 0.7
YY46
Around 0.6
Processing modifier
3
Toughener
Add as needed
Self-production or outsourcing
30-40
Door frame, door reference formula
Name
Add amount
PVCS-1000
50
PVCS-700
50
Wood flour
20
Light calcium
100
Stabilizer YY602
5
YY45
Around 0.8
YY46
Around 0.7
YY50
6
YY52
2-3
CCR10
1
CCR20A
0.8
Toughener
Add as needed
Wood-plastic foam board, foam board construction template, co-extruded foam board reference formula
Name
Add amount
S700
50
S1000
50
Stabilizer YY602
5-6
CCR10
0.8
CCR20A
0.7
Wood flour
10-20
Calcium carbonate
30-40
YY45
0.7-0.8
YY46
0.7-0.8
OA6
0.2
Flow modifier
Add as needed
Strengthening and toughening agent
5-6
Processing modifier
3
Self-return
30
Yy50
2
YY52
7
ABS wood plastic foam reference formula
Name
Add amount
ABS
100
Wood flour
30-60
Inorganic
10
stabilizer
1.5
PA08
1-2
ABS grafting compatibilizer
Add as needed
YY900
Add as needed
PA01
5
PS wood-plastic foaming formula
Name
Add amount
HIPS
30
GPPS
40
Wood flour
30-50
Stabilizer PA808
2.5-4
PA01
5
CCR101
1-1.5
PVC wood plastic profile, ecological wood formula
PVC
100
Wood flour
25-35
Light calcium
50-45
stabilizer
4.5-5.5
YY52
8
CCR10
0.8-0.9
CCR20A
0.6-0.8
YY47
0.6-0.8
YY48
0.6-0.8
YY49
0.4-0.6
YY42
0.2-0.3
Processing modifier
2-3
Other functional additives
Add as needed
Toner
Add as you like
PP, PE wood plastic extrusion formula
Name
Add amount
PP, PE return material
100
Wood flour
250
Inorganic
30-50
PA003
7-8
HD3304 / HD3304
8
1010
Add as needed
UV absorber
Add as needed
Toner
Add as needed
PP / PE wood plastic injection formula
Name
Add amount
PP / PE return or new material
100
Wood flour, bamboo flour
30-60
Inorganic
5-10
PA04
2-3
HD3304 / HD3303
Add as needed
other
Add as needed
PVC wood plastic injection formula
Name
Add amount
PVC
100
Bamboo flour or wood flour
20-25
Calcium carbonate
25-30
PB40
1.5-2
PA07
1.5-2
stabilizer
Add on demand and stabilizer type
Processing modifier
2-3
Reference formula for PVC wood-plastic doors and windows
Name
Add amount
PVC
100
Wood flour
25-30
Calcium carbonate
25-30
stabilizer
Add as needed (considering environmentally friendly and non-environmental stabilizers)
YY50
6-8
CCR10
0.5
CCR20A
0.5-0.8
PA100
1.5
PA48
5-8
YY47
0.6-0.8
YY48
0.6-0.8
YY49
0.4-0.6
YY42
0.2-0.3
The
PVC wood plastic foam floor formula
Name
Add amount
PVC
100
Calcium carbonate
65-70
Wood flour
40-45
stabilizer
4.5-5.5
Macromolecular blowing agent CCR10
0.8
Macromolecular blowing agent CCR20A
0.6
YY50
3.5
YY52
4.5
YY47
0.7-0.8
YY48
0.6-0.7
YY49
0.7-0.8
The
PVC calcium plastic floor formula
Name
Add amount
PVC
30
Calcium carbonate
80-90
PVC waste
30-50
YY20A
3
stabilizer
5-6
A-88
1.2
Remarks: The calcium-plastic floor produced by this formula has a smooth surface, good mechanical strength, stable production, production capacity, and low formula cost can achieve more than 2000 yuan a ton
PVC wood plastic non-foaming floor formula
Name
Add amount
PVC
100
Wood flour
165
Inorganic
40-70
stabilizer
5.5-6
YY05
3.5-4
A-88
1.3-1.5
Toughening enhancer
According to the situation
The wood-plastic floor made of cold-top technology has good wood feeling and strength. It does not contain formaldehyde and environmental protection products. It does not absorb water, mildew, insects, deformation, and warpage. Mainly used indoors and outdoors.
PVC wood-plastic vacuum shaping process to produce profiles, reference formula for flooring
Name
Add amount
PVC
100
Wood flour
80-100
Inorganic
30-50
PA07
2.5-5
PB-8
1.5
PA-100
2
Flow modifier
2
Toughening modifier
Please add
PP / PE floor formula
Name
Add amount
PP / PE material
100
Wood flour
250
Talc or calcium powder
30
PA-3
7.6-7
Compatibilizer
7-8
Anti-aging agent (*** agent UV absorber)
According to the situation
Toner
