Inner rib reinforced corrugated pipe production line, pursuing green fashion
Inner rib reinforced corrugated pipe production line, pursuing green fashionThe main purpose of the inner rib reinforced corrugated pipe production line is as a measuring element for pressure measurement. The corrugated pipe refers to a tubular elastic sensitive element connected by a foldable corrugated sheet along the folding elastic direction. Bellows are widely used in the appearance of the instrument. Convert pressure into displacement or force. The bellows has a thinner wall and higher sensitivity, and the measurement scale is from tens of Pa to tens of MPa. The open end is fixed, and the sealed end is in a comfortable condition, and auxiliary coil springs or reeds are used to add elasticity. When working, under the effect of internal pressure, it stretches along the length of the pipe, causing the movable end to produce a displacement that is bound to the pressure. There are also carat pipe production line, PE hollow wall winding pipe equipment and spiral corrugated pipe production line, etc.
The production line of ribbed reinforced bellows is often combined with displacement sensors to form a pressure sensor that outputs electricity, and is sometimes used as a barrier element. Since the expansion of the bellows requires a larger volume change, its response speed is lower than that of the Bourdon tube. The bellows is suitable for measuring low pressure. A cylindrical thin-walled corrugated shell with multiple transverse corrugations. The bellows has elasticity and can be displaced under the effect of pressure, axial force, transverse force or bending moment. The bellows is widely used in the appearance of the instrument, and its main purpose is as a measuring element of the pressure measurement surface, which converts pressure into displacement or force. The bellows has a thinner wall and higher sensitivity, and the measurement scale is from tens of Pa to tens of MPa. In addition, the bellows can also be used as a sealing barrier element to separate the two media or prevent harmful fluids from entering the measuring part of the device.
If you want to know more about it please do not hesitate to
contact me. WhatsApp:+86-15966835076.
