Description
MACHINE DISCRIPTION:
1. SJ-90/30 extruder 1 set
1.1PP PE screw, length to diameter ratio L/D=33:1, screw diameter 90mm, maximum screw speed 70r/min. Place of Origin: Zhoushan
1.2 Extrusion capacity 10-260KG/H
1.3 The screw and barrel are made of 38CrMoALA, and the nitriding depth is 0.5-0.7mm. Hard chrome plated on the surface
1.4 The barrel adopts cast aluminum heating, 5 zones heating, heating power 4.8KW/zone; 5 stages cooling, adopts fan cooling, cooling power 0.18KG×5. Place of Origin: Yancheng
1.5 The main motor adopts a frequency conversion motor, the motor power is 75KW, the transmission mode is direct-connected, the place of production is Shandong Xuguang, and the frequency converter is Qingdao Huahao Kecheng electrical product.
1.6ZLY-250 horizontal reduction gearbox, gear reduction, the gear adopts hard surface, the gear material is 20CrMoTi deep nitrogen, and the teeth are ground. Long service life, low noise and high torque. Country Mao
1.7 The electrical control parts, contactors, and electrical appliances are Siemens products. Optimized design of electrical control cabinet, self-made by our company
dKC intelligent temperature control meter control system, using PID type temperature fluctuation self-tuning adjustment
I. Overview
1. Conditions of use: 380V/3 Phase/ 50HZ
2. Material: PE
3. Specifications
Width: 1450mm
Thickness: 8mm-15mm
1. SJ-90/30 extruder 1 set
1.1PP PE screw, length to diameter ratio L/D=33:1, screw diameter 90mm, maximum screw speed 70r/min. Place of Origin: Zhoushan
1.2 Extrusion capacity 10-260KG/H
1.3 The screw and barrel are made of 38CrMoALA, and the nitriding depth is 0.5-0.7mm. Hard chrome plated on the surface
1.4 The barrel adopts cast aluminum heating, 5 zones heating, heating power 4.8KW/zone; 5 stages cooling, adopts fan cooling, cooling power 0.18KG×5. Place of Origin: Yancheng
1.5 The main motor adopts a frequency conversion motor, the motor power is 75KW, the transmission mode is direct-connected, the place of production is Shandong Xuguang, and the frequency converter is Qingdao Huahao Kecheng electrical product.
1.6ZLY-250 horizontal reduction gearbox, gear reduction, the gear adopts hard surface, the gear material is 20CrMoTi deep nitrogen, and the teeth are ground. Long service life, low noise and high torque. Country Mao
1.7 The electrical control parts, contactors, and electrical appliances are Siemens products. Optimized design of electrical control cabinet, self-made by our company
dKC intelligent temperature control meter control system, using PID type temperature fluctuation self-tuning adjustment
I. Overview
1. Conditions of use: 380V/3 Phase/ 50HZ
2. Material: PE
3. Specifications
Width: 1450mm
Thickness: 8mm-15mm
The above parameters are for reference only
